Delphi STUN Server and Client

STUN Server

TsgcSTUNServer is the server that implements the STUN protocol and allows to process binding requests from STUN clients.

The STUN server can be configured with or without Authentication, can verify Fingerprint Attribute, send an alternate server and more.

Basic Usage

Usually stun servers runs on UDP port 3478 and don't require authentication, so in order to configure a STUN server, set the listening port (by default 3478) and start the server.

Configure the server

• Port: the listening Server port, example: 3478

Set the property Active = True to start the STUN server.

Check the following Delphi Code which shows how start a new Delphi STUN Server.

oSTUN := TsgcSTUNServer.Create(nil);
oSTUN.Port := 3478;
oSTUN.Active := True;

Long-Term Credentials

Usually STUN Servers are configured without Authentication, so any STUN client can send a binding request and expect a response from server without Authentication.

sgcWebSockets STUN Server supports Long-Term Credentials, so you can configure TsgcSTUNServer to only allow binding requests with Long-Term credentials info.

To configure it, access to STUNOptions.Authorization property and enable it.

Then access to LongTermCredentials property and enabled it. By default, this type of authorization is already configured with a Realm string and with a default StaleNonce value of 10 minutes (= 600 seconds).

Check the following Delphi Code which shows how create a new Delphi STUN Server with Long-Credentials enabled.

oSTUN := TsgcSTUNServer.Create(nil);
oSTUN.Port := 3478;
oSTUN.STUNOptions.Authentication.Enabled := True;
oSTUN.STUNOptions.Authentication.LongTermCredentials.Enabled := True;
oSTUN.STUNOptions.Authentication.LongTermCredentials.Realm := 'sgcWebSockets';
oSTUN.STUNOptions.Authentication.LongTermCredentials.StaleNonce := 600;
oSTUN.Active := True;


procedure OnSTUNRequestAuthorization(Sender: TObject; const aRequest: TsgcSTUN_Message; const aUsername, aRealm: string; var Password: string);
begin
  if aUsername = 'my-user' then
    Password := 'my-password';
end;

STUN Client

 TsgcSTUNClient is the client that implements the STUN protocol and allows to send binding requests to STUN servers.

The components allows to use UDP and TCP as transport, and when used UDP as transport implements a Retransmission mechanism to re-send requests if the response not arrived after a small time.

Basic usage

Usually stun servers runs on UDP port 3478 and don't require authentication, so in order to send a STUN request binding, fill the server properties to allow the client know where connect and Handle the events where the component will receive the response from server.

Configure the server

• Host: the IP or DNS name of the server, example: stun.sgcwebsockets.com
• Port: the listening Server port, example: 3478

Call the method SendRequest, to send a request binding to STUN server.

Handle the events

• If the server returns a successful response, the event OnSTUNResponseSuccess will be called and you can access to the Binding information reading the aBinding object.
• If the server returns an error, the event OnSTUNResponseError will be called and you can access the Error Code and Reason reading the aError object.
•


oSTUN := TsgcSTUNClient.Create(nil);
oSTUN.Host := 'stun.sgcwebsockets.com';
oSTUN.Port := 3478;
oSTUN.SendRequest;


procedure OnSTUNResponseSuccess(Sender: TObject; const aMessage: TsgcSTUN_Message; const aBinding: TsgcSTUN_ResponseBinding);
begin
  DoLog('Remote IP: ' + aBinding.RemoteIP + '. Remote Port: ' + IntToStr(aBinding.RemotePort));
end;


procedure OnSTUNResponseError(Sender: TObject; const aMessage: TsgcSTUN_Message; const aError: TsgcSTUN_ResponseError);
begin
  DoLog('Error: ' + IntToStr(aError.Code) + ' ' + aError.Reason);
end;
