DataSnap with WebSocket and HTTP/2

There are 3 different types of server that you can use as a replacement of TIdHTTPWebBrokerBridge default Indy server.

Using any of these servers, you can use HTTP and WebSocket protocol using the same listening port. You can dispatch custom http requests using OnHTTPRequest event available on any of these servers.

Sample Code

In order to use any of these servers, you must replace the default Indy WebBrokerBridge server and set the required properties in order to run it.

Check the following code which replace the default server and make use of TsgcWSHTTPWebBrokerBridgeServer (supports HTTP + WebSocket protocols).

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
unit FormUnit1;
interface
uses
  Winapi.Messages, System.SysUtils, System.Variants,
  System.Classes, Vcl.Graphics, Vcl.Controls, Vcl.Forms, Vcl.Dialogs,
  Vcl.AppEvnts, Vcl.StdCtrls, sgcWebSocket_Server_WebBrokerBridge, Web.HTTPApp,
  sgcWebSocket_Classes, sgcWebSocket_Types;
type
  TForm1 = class(TForm)
    ButtonStart: TButton;
    ButtonStop: TButton;
    EditPort: TEdit;
    Label1: TLabel;
    ApplicationEvents1: TApplicationEvents;
    ButtonOpenBrowser: TButton;
    Button1: TButton;
    chkSSL: TCheckBox;
    procedure FormCreate(Sender: TObject);
    procedure ApplicationEvents1Idle(Sender: TObject; var Done: Boolean);
    procedure Button1Click(Sender: TObject);
    procedure ButtonStartClick(Sender: TObject);
    procedure ButtonStopClick(Sender: TObject);
    procedure ButtonOpenBrowserClick(Sender: TObject);
  private
    FServer: TsgcWSHTTPWebBrokerBridgeServer;
    procedure StartServer;
  private
    procedure OnWebSocketMessage(aConnection: TsgcWSConnection; const aText:
        string);
  end;
var
  Form1: TForm1;
implementation
{$R *.dfm}
uses
  WinApi.Windows, Winapi.ShellApi, Datasnap.DSSession;
procedure TForm1.ApplicationEvents1Idle(Sender: TObject; var Done: Boolean);
begin
  ButtonStart.Enabled := not FServer.Active;
  ButtonStop.Enabled := FServer.Active;
  EditPort.Enabled := not FServer.Active;
end;
procedure TForm1.ButtonOpenBrowserClick(Sender: TObject);
var
  vURL: string;
  vProtocol: string;
begin
  StartServer;
  vProtocol := 'http';
  if chkSSL.Checked then
    vProtocol := vProtocol + 's';
  vURL := Format(vProtocol + '://127.0.0.1:%s', [EditPort.Text]);
  ShellExecute(0,
        nil,
        PChar(vURL), nil, nil, SW_SHOWNOACTIVATE);
end;
procedure TForm1.ButtonStartClick(Sender: TObject);
begin
  StartServer;
end;
procedure TerminateThreads;
begin
  if TDSSessionManager.Instance <> nil then
    TDSSessionManager.Instance.TerminateAllSessions;
end;
procedure TForm1.Button1Click(Sender: TObject);
var
  vURL: string;
  vProtocol: string;
begin
  StartServer;
  vProtocol := 'http';
  if chkSSL.Checked then
    vProtocol := vProtocol + 's';
  vURL := Format(vProtocol + '://127.0.0.1:%s/sgcWebSockets.html', [EditPort.Text]);
  ShellExecute(0,
        nil,
        PChar(vURL), nil, nil, SW_SHOWNOACTIVATE);
end;
procedure TForm1.ButtonStopClick(Sender: TObject);
begin
  TerminateThreads;
  FServer.Active := False;
  FServer.Bindings.Clear;
end;
procedure TForm1.FormCreate(Sender: TObject);
begin
  FServer := TsgcWSHTTPWebBrokerBridgeServer.Create(Self);
  FServer.OnMessage := OnWebSocketMessage;
end;
procedure TForm1.OnWebSocketMessage(aConnection: TsgcWSConnection; const aText:
    string);
begin
  aConnection.WriteData(aText);
end;
procedure TForm1.StartServer;
begin
  if not FServer.Active then
  begin
    FServer.Bindings.Clear;
    FServer.DefaultPort := StrToInt(EditPort.Text);
    if chkSSL.Checked then
    begin
      FServer.SSLOptions.CertFile := 'sgc.pem';
      FServer.SSLOptions.KeyFile := 'sgc.pem';
      FServer.SSLOptions.RootCertFile := 'sgc.pem';
      FServer.SSLOptions.Port := StrToInt(EditPort.Text);
      FServer.SSLOptions.Version := tls1_2;
    end;
    FServer.SSL := chkSSL.Checked;
    FServer.Active := True;
  end;
end;
end.
