Faster WebSocket Compression

WebSocket compression is essential for reducing bandwidth and improving responsiveness, especially when transmitting repetitive data like JSON payloads. The permessage-deflate extension compresses every WebSocket frame on the fly — but the speed of that compression directly impacts your application's throughput.

Starting with sgcWebSockets 2026.4.0, the permessage-deflate implementation has been completely rewritten for significantly faster performance. In our benchmarks, small messages compress and decompress up to 15x faster, with measurable gains across all payload sizes.

What Changed?

The previous implementation initialized and destroyed the compression engine on every single WebSocket frame. This meant that even a tiny 1 KB message paid the full cost of setting up the compressor, compressing the data, and then tearing everything down — only to repeat the entire process for the next message.

The new implementation keeps the compression engine alive across frames. It is initialized once when the first frame arrives and reused for the lifetime of the connection. This eliminates the per-frame setup overhead and also allows the engine to learn from previous messages, resulting in faster compression of repetitive data patterns.

In addition to the persistent compression context, the new implementation includes several other optimizations:

• Pre-allocated memory buffers — Buffers are allocated once and reused, avoiding repeated memory allocation on every frame.
• Direct memory access — When the input is already in memory, the engine reads it directly without copying it into intermediate buffers first.
• Reused temporary streams — Internal working streams are created once in the constructor instead of being created and destroyed on every compress/decompress call.

Benchmark Results

We ran 10,000 compress + decompress round-trips for each message size. Every round-trip compresses a JSON payload and then decompresses it back, verifying the output matches the original. The test was performed on a Windows 64-bit machine compiled with Delphi 12 Athens.

Default Configuration (persistent context)

This is the default mode where the compression context is maintained across frames — the most common real-world scenario:

With NoContextTakeOver (independent frames)

When NoContextTakeOver is enabled, each frame is compressed independently. Even in this mode, the buffer reuse and direct memory access optimizations provide a solid improvement:

Who Benefits Most?

The improvement is most dramatic for applications that exchange many small messages — which is exactly the typical WebSocket use case:

Fully Compatible

The optimization is fully transparent — no code changes are needed in your application. The compressed data on the wire is identical to the previous version, so upgraded servers work seamlessly with existing clients and vice versa.

The new implementation supports all platforms and compilers:

• Delphi 7 through Delphi 13 (including C++Builder)
• Windows, macOS, Linux, Android, iOS
• 32-bit and 64-bit targets

Upgrade to 2026.4.0

The permessage-deflate optimization is available in sgcWebSockets 2026.4.0. Simply update to the latest version and your WebSocket connections will automatically benefit from faster compression. Download at esegece.com.

Special thanks to Michael for contributing the initial optimized implementation that inspired this work. His research into persistent zlib contexts and direct memory access laid the foundation for these performance improvements.
