Delphi Login With Passkeys, SAML SSO, LDAP and TOTP 2FA

The login screen is the one part of a business application that every customer has an opinion about. Can we sign in with our Entra ID account. Does it support passkeys. Our auditors want two-factor. Our users are in Active Directory, why do they need another password. And the mail your application sends stopped working the day Microsoft 365 refused the password in the SMTP settings.

Each of those questions is a protocol with its own specification, its own XML or ASN.1, and its own ways to be almost right. The new Enterprise authentication components answer them as Delphi components. They ship in the Enterprise and All-Access editions of sgcWebSockets and in the sgcAuth pack, and the same components are part of sgcWebSockets .NET.

Passkeys, the Way Users Expect Them

The WebAuthn server now covers what people actually mean when they say passkeys:

SAML Single Sign-On

Large customers do not want their staff to have an account in your application. They want them to sign in with the identity provider the company already runs. TsgcSAMLServiceProvider makes your application a SAML 2.0 service provider for Entra ID, Okta, AD FS, Google Workspace and Keycloak. The identity provider does the login, your application receives an assertion, and the signature on that assertion is validated before you ever see a user name.

Active Directory and LDAP Login

For the application that runs inside the company network, the users already have a password: their Windows one. TsgcLDAPClient checks a user name and password against Active Directory or any LDAP directory, over LDAPS or StartTLS so the password never crosses the network in clear. Set Security to ldapsecLDAPS or ldapsecStartTLS and call Authenticate.

Knowing who the user is only answers half the question. GetUserGroups returns the groups the account belongs to, nested groups included, so “is this user an invoice approver” is one call instead of a recursive search you write and debug yourself.

Two-Factor Codes From an Authenticator App

TsgcTOTPAuthenticator produces and checks the six digit codes of Google Authenticator, Microsoft Authenticator and every other TOTP app. Enrolment is a secret and a URI you show as a QR code. Sign-in is one call:

uses
  sgcAuth_TOTP, sgcBase_Helpers;

var
  oTOTP: TsgcTOTPAuthenticator;
  vSecret, vURI: string;
  vLastStep: Int64;
begin
  oTOTP := TsgcTOTPAuthenticator.Create(nil);
  try
    oTOTP.Issuer := 'MyApp';

    // enrolment: store vSecret with the user, show vURI as a QR code
    vSecret := oTOTP.GenerateSecret;
    vURI := oTOTP.GetProvisioningURI('john@example.com', vSecret);

    // sign-in: vLastStep is the last step accepted for this user, -1 the first time
    vLastStep := -1;
    if oTOTP.VerifyCode(vSecret, txtCode.Text,
      StrToInt64(GetDateTimeUnix(Now)), vLastStep) then
      ShowMessage('Signed in') // save vLastStep, this code is now spent
    else
      ShowMessage('Wrong, expired or already used');
  finally
    oTOTP.Free;
  end;
end;

That overload is the replay protection: a code that has already been accepted is refused, even inside its own thirty seconds, so a code read over someone's shoulder is worth nothing once it has been used. For the day the phone is lost, GenerateRecoveryCodes fills a list with one-time recovery codes. Store them the way you store passwords.

OpenID Connect Sign-In

TsgcHTTP_OIDC_Client signs users in with any OpenID Connect provider. It reads the provider's discovery document, so the configuration is an issuer URL and a client ID rather than a list of endpoints copied by hand. It validates the ID token it receives, and the same signing keys validate the bearer tokens that reach your own REST API, including tokens from Entra ID multi-tenant applications, where every customer's tenant signs with its own issuer.

OAuth2 for Microsoft 365 and Gmail Mail

Microsoft 365 and Gmail expect OAuth2, not a password, from SMTP, IMAP and POP3. TsgcMailOAuth2 obtains the access token, refreshes it, and builds the XOAUTH2 string your SMTP, IMAP or POP3 session signs in with. Choose the provider and the protocols, give it your client ID, and keep the refresh token when OnTokensChanged fires. A service or a console application with no browser can use the device code flow instead.

Try the Demos

Every component has a runnable demo in Demos\26.Authentication:

Documentation

Where to Get Them

The components are included in the Enterprise and All-Access editions of sgcWebSockets, for Delphi, C++ Builder and .NET. If you only need authentication, the sgcAuth pack has them on their own. They are additive: nothing changes in an existing application until you drop one on a form.

Watch It

There is a short video, “Delphi login with passkeys, SAML SSO, Active Directory LDAP and TOTP 2FA”, on the eSeGeCe channel.

Questions, feedback or help wiring this into your login page? Get in touch. You will get a reply from the people who wrote the code.
